Boss PS-6 Harmonist Effects Pedal

You can even control pitch with an optional expression pedal. The harmony function is fast and simple to use, and supports a variety of interval patterns. It’s easy to create rich, three-voice harmony: choose a major or minor key, and set SHIFT to 3-VOICE—that’s it! The PS-6 Harmonist is an unbeatable combination of superior sound quality, ease of use, and powerful pitch effects, all under one hood.

Features

• Four effect modes in one stompbox: Harmony, Pitch Shifter, Detune, and S-BEND (Super Bend)
• Easily create two- or three-voice harmonies with selectable key and voicing
• High-quality pitch shifting
• Three-voice Detune capability
• Super Bend provides up to four octaves of extreme pitch bending
• Control pitch via expression pedal (optional BOSS FV-500L/H or Roland EV-5)
• BOSS five-year warranty

Specs

• Nominal Input Level: -20 dBu
• Input Impedance: 1 M ohm
• Nominal Output Level: -20 dBu
• Output Impedance: 1 k ohm
• Recommended Load Impedance: 10 k ohms or greater
• Bypass: Buffered bypass
• Controls: MODE knob, KEY/FALL TIME knob, SHIFT knob, BALANCE/RISE TIME knob, Pedal switch
• Indicator: CHECK indicator (Used for indication of check battery)
• Connectors: INPUT jack: 1/4-inch phone type, OUTPUT jack A(MONO)/B: 1/4-inch phone type, EXP jack: TRS 1/4-inch phone type, DC IN jack
• Power Supply: Alkaline battery (9 V, 6LR61), AC adaptor (PSA series: sold separately)
• Current Draw: 65 mA
• Expected battery life under continuous use: Alkaline: Approx. 3 hours
  *These figures will vary depending on the actual conditions of use.
• Accessories: Leaflet ("USING THE UNIT SAFELY," "IMPORTANT NOTES," and "Information"), Dry battery (9 V, 6LR61)
